Lexicon, Inc.
MC-12 Serial Communications Protocol Printed on: 08/18/03
© 2003 Lexicon, Inc. All rights reserved. 16 of 94
7.3.2.2 MC-12 Response
The MC-12 will reset, clear any saved system and effect parameters in Nonvolatile RAM, and restore the
factory default system and effect parameters. After reset the MC-12 will go through a soft power-up
initialization. This includes transmitting the “Wakeup Notification Packet”.
7.3.3 MC-1 Send IR Command (MC-12, MC-1)
Transmits MC-1 IR command key codes to the MC-12.
This command has been maintained for backward compatibility to the MC-1. The MC-1 IR code
functionality has been mapped to the MC-12 IR code functionality as per the MC-1 to MC-12 IR code
table. MC-12 users should use the command described in 7.3.40 (MC-12_Send_IR_Command).
7.3.3.1 Command Packet Description
Application Header:
Command DC_CMD_IR 0x14
Data Count 1 0x01
Application Data:
Data[0] KeyCode nn
7.3.3.2 Data Description
KeyCode:
Data Type: Unsigned 8 bit integer
Valid Values: Appendix C MC-1 IR-Codes
7.3.3.3 MC-12 Response
The KeyCode is processed as a valid IR code. No acknowledgment will be sent from MC-12.
7.3.3.4 Data Validation
The KeyCode data will be verified as a legal IR code. If the Code is not valid the MC-12 will not respond.
7.3.4 Get Unit Configuration (MC-12, MC-1)
Request to MC-12 for its current unit configuration.
This command is supported for backward compatibility. MC-12 users should use the command described
in 7.3.39 (MC-12_Get_Unit_Configuration). MC-12 will respond with “Unit Configuration Packet”. The
HOST should use this information to determine if any information saved by the HOST is current.
7.3.4.1 Command Packet Description
Application Header:
Command DC_CMD_GET_CONFIG 0x15
Data Count 0 0x00
Application Data:
N/A
