Lexicon MC-12 V3.0 - SERIAL COMMUNICATIONS PROTOCOL DEFINITION REV 1-5 - Appendix D MC-12 IR Codes

Lexicon, Inc.
MC-12 Serial Communications Protocol Printed on: 08/18/03
© 2003 Lexicon, Inc. All rights reserved. 58 of 94
Appendix D MC-12 IR Codes
Main
Button2
Zone-2
Button3
Record
Button4
Shift
Button9
KEY
LABEL DATA
(hex)
FUNCTION DATA
(hex)
FUNCTION DATA
(hex)
FUNCTION DATA (hex)
Setup LIGHT None LIGHT None LIGHT None LIGHT None
1 MAIN_ON_STDBY 0x05 ZONE_ON_STDBY 0x05 REC_ON_STDBY 0x05 SHIFT_STDBY 0x05
2 MAIN None MAIN None MAIN None MAIN None
3 ZONE None ZONE None ZONE None ZONE None
4 REC None REC None REC None REC None
5 Deleted None Deleted None Deleted None Deleted None
6 Deleted None Deleted None Deleted None Deleted None
7 Deleted None Deleted None Deleted None Deleted None
8 Deleted None Deleted None Deleted None Deleted None
9 SHIFT None SHIFT None SHIFT None SHIFT None
10 MAIN_DVD_1 0x20 ZONE_DVD_1 0x60 REC_DVD_1 0xE0 MAIN_OFF 0xA0
11 MAIN_DVD_2 0x21 ZONE_DVD_2 0x61 REC_DVD_2 0xE1 ZONE_OFF 0xA1
12 MAIN_LD 0x22 ZONE_LD 0x62 REC_LD 0xE2 REC_OFF 0xA2
13 MAIN_TV 0x23 ZONE_TV 0x63 REC_TV 0xE3 LOUDNESS_ON 0xA3
14 MAIN_SAT 0x24 ZONE_SAT 0x64 REC_SAT 0xE4 LOUDNESS_OFF 0xA4
15 MAIN_VCR 0x25 ZONE_VCR 0x65 REC_VCR 0xE5 Reserved 0xA5
16 MAIN_CD 0x26 ZONE_CD 0x66 REC_CD 0xE6 BASS_INCR 0xA6
17 MAIN_PVR 0x27 ZONE_PVR 0x67 REC_PVR 0xE7 TREBLE_INCR 0xA7
18 MAIN_GAME 0x28 ZONE_GAME 0x68 REC_GAME 0xE8 TILT_INCR 0xA8
19 MAIN_TAPE 0x29 ZONE_TAPE 0x69 REC_TAPE 0xE9 BASS_DECR 0xA9
20 MAIN_TUNER 0x2A ZONE_TUNER 0x6A REC_TUNER 0xEA TREBLE_DECR 0xAA
21 MAIN_AUX 0x2B ZONE_AUX 0x6B REC_AUX 0xEB TILT_DECR 0xAB
22 MODE_INCR 0x1A TRIGGER1_ON 0x5A TRIGGER2_On 0xDA ON 0x9A
23 MODE_DECR 0x1B TRIGGER1_OFF 0x5B TRIGGER2_OFF 0xDB STANDBY 0x9B
24 FP 0x04 ZONE_VOL_N15DB 0x44 REC_VOL_N15DB 0xC4 VOL_N15DB 0x84
25 BLUE 0x03 ZONE_VOL_N30DB 0x43 REC_VOL_N30DB 0xC3 VOL_N30DB 0x83
26 OSD 0x02 Reserved 0x42 Reserved 0xC2 EQ_OFF 0x82
27 VOL_INCR 0x17 ZONE_VOL_INCR 0x57 REC_VOL_INCR 0xD7 VOL_03DB 0x97
28 VOL_DECR 0x16 ZONE_VOL_DECR 0x56 REC_VOL_DECR 0xD6 VOL_N03DB 0x96
29 STAT 0x1C ZONE_STATUS 0x5C REC_STATUS 0xDC INPUT_STATUS 0x9C
30 MUTE 0x15 ZONE_MUTE 0x55 REC_MUTE 0xD5 FULL_MUTE 0x95
31 UP_ARROW 0x01 SUB_ADJ_INCR 0x41 Reserved 0xC1 FADER_FRONT 0x81
32 DN_ARROW 0x1D SUB_ADJ_DECR 0x5D Reserved 0xDD FADER_REAR 0x9D
33 LEFT_ARROW_DONE 0x0A ZONE_BAL_LEFT 0x4A REC_BAL_LEFT 0xCA BAL_LEFT 0x8A
34 RIGHT_ARROW_SELE
CT
0x08 ZONE_BAL_RIGHT 0x48 REC_BAL_RIGHT 0xC8 BAL_RIGHT 0x88
35 MENU 0x09 ZONE_BAL_CENTER 0x49 REC_BAL_CENTER 0xC9 BAL_CENTER 0x89
36 MAIN_TOGGLE_7_5 0x1E Reserved 0x5E Reserved 0xDE MAIN_SRC_MODE 0x9E
37 MAIN_2_CHANNEL 0x1F Reserved 0x5F Reserved 0xDF BYPASS 0x9F
38 THX_LOGO 0x0B Reserved 0x4B Reserved 0xCB THX_EX_TOGGLE 0x8B
39 DOLBY_LOGO 0x0C Reserved 0x4C Reserved 0xCC DOLBY_EX_TOGGLE 0x8C
40 LOGIC7_LOGO 0x0D Reserved 0x4D Reserved 0xCD Reserved 0x8D
41 TV_L_LOGO 0x0E Reserved 0x4E Reserved 0xCE MONO_LOGIC 0x8E
42 DTS_LOGO 0x0F Reserved 0x4F Reserved 0xCF DTS_ES_TOGGLE 0x8F
43 MUSIC 0x10 Reserved 0x50 Reserved 0xD0 MUSIC_SURROUND 0x90
44-55 Deleted None Deleted None Deleted None Deleted None
