7.3.6 Get Zone 2 Status (MC-12, MC-1)
This command is a request to MC-12 for current Zone 2 Status. MC-12 will respond with “Zone2 Status
Packet”.
This command has been maintained for backward compatibility with MC-1. In order to maintain backward
compatibility, the MC-12 Parameters have been mapped to the MC-1 parameters as described in each Data
Description. MC-12 users should be using the command described in 7.3.46 (MC12_Get_Zone_2_Status).
7.3.6.1 Command Packet Description
Application Header:
Command DC_CMD_GET_ZONE2_STATUS 0x17
Data Count 0 0x00
Application Data:
N/A
7.3.6.2 Zone2 Status Response Packet
Application Header:
Command DC_RESP_ZONE2_STATUS 0x82
Data Count 5 0x05
Application Data:
Data[0] Zone2 Volume nn
Data[1] Assigned Zone 2 Input nn
Data[2] Zone2 Mute Active nn
Data[3] Record Active nn
Data[4] Zone2 Balance nn
7.3.6.3 Data Description
Zone2 Volume:
Data Type: Unsigned 8 bit integer.
Maximum Value: 92
Conversion: 0 = -80 dB
92 = +12 dB
Assigned Zone 2 Input:
Indicates the Zone 2 input that is currently assigned for the zone 2 outputs.
Data Type: Unsigned 8 bit integer.
Definition/Conversion: Appendix F MC-12 Input Ids
Zone2 Mute Active:
Data Type: Boolean.
TRUE: Zone2 Outputs are active.
FALSE: Zone 2 Outputs are not active.
Record Active:
Data Type: Boolean.
TRUE: Record Zone Output is active
FALSE: Record Zone Output is not Active.
