@@@DIGITAL STATUS
• Available when the remote control SHIFT-STAT command is
executed and a sample rate is detected and an unknown
digital input source is present. When the input source is
identified, the appropriate STATUS menu will appear on the
on-screen display.
Parameter Values
INPUT The name of the selected input
MODE The name of the selected listening mode
INPUT TYPE ---
SAMPLE RATE 44.1kHz, 48kHz, 88.2kHz, 96kHz
STATUS menu parameter descriptions begin on page 28 of this
document and on page 5-20 of the MC-12 User Guide (Rev 1).
