Software V
ersion 2.0 Release &
Errata Notes
Lexicon
42
@
@
@
INST
ALLA
TION WORKSHEET
This Installation W
orksheet that begins below is based on Software Version 2.0. It replaces Installation W
orksheets that appear in all previous
documentation.
v2.0
INPUT SETUP
D
VD1
DVD2
LD
TV
SA
T
VCR
CD
PVR
GAME
T
APE
TUNER
AUX
NAME
DIGIT
AL IN
ANALOG IN
ANLG IN L
VL
VIDEO IN
COMPONENT IN
2-CH
D
5.1a
MAIN ADV
INPUT SELECT
ANALOG BYP
ASS
S-VIDEO 16:9
S-VIDEO OSD 4:3
COMPONENT OSD
ZONE2 IN
RECORD IN
RECORD ADV
ANLG IN L
VL
DIGIT
AL BYP
ASS
DIG OUT RA
TE
RECORD
41
43
Table of Contents
Documentation Conventions
3
Caution
3
Table of Contents
4
Zone 2 & Record Zone Volume Control
5
To Use the Front Panel Volume Knob to Adjust Zone 2 Volume Level
5
To Use the Front Panel Volume Knob to Adjust Record Zone Volume Level
5
Standby
6
Revised Remote Control Command Matrix
6
Revised Input Setup Menus
11
A • ZONE2 in or RECORD in
11
ANLG (Analog)
12
Digital
12
DMIX (Downmix)
12
Trigger Setup Menu
13
Remote Only
14
Program Operation Parameters
14
New Listening Modes
14
Logic7 Music Surround
15
Logic7 Tv
15
Enhanced Logic7 Film
15
Dts NEO:6 FILM
16
Dts NEO:6 MUSIC
16
Nightclub
17
Concert Hall
17
Church
18
Cathedral
18
Dolby Digital
19
Dolby Digital Ex
19
Dolby Digital Ex & Dolby Digital
19
5.1A LOGIC7 FILM
20
5.1A LOGIC7 MUSIC
20
THX Surround EX & 5.1A THX
21
THX Surex
21
Standard
22
2-Channel
22
Status Menu Level Meters
23
To Access and Navigate the STATUS Menu for the Current Input Source
23
Status Menus
23
2Ch Status
24
Dolby D Status
24
Analog Status
25
Dts(-ES) STATUS
25
Bypass Status
26
2Ch Bypass Status
26
Digital Status
27
Center Depth
28
Dialog Offset
28
Encoding
28
Listening Mode & STATUS Menu Parameter Descriptions
28
Es Encoding
29
Ex Encoding
29
Front Steering
30
Liveness
30
MID Rt
30
Pre-Delay
30
Surround Ex
31
Word Length
31
Errata Notes
31
Revised Menu Tree
33
SETUP Menu Branch
34
AUDIO CONTROLS Menu Branch
38
MODE ADJUST Menu Branch
38
FACTORY SETTINGS Menu
41
Input Setup
42
Installation Worksheet
42
Volume Control Setup
43
Audio Controls
43
Lock Options
43
Trigger Setup
43
Display Setup
43
Rear Panel Config
43
Speaker Setup
43
Symbols
46
Numbers
46
Index
46
Component
47
Custom
47
