Setup Lexicon
3-64
POSITION TOP, CENTER, BOTTOM
Controls the vertical position of the two-line status on the display
device screen. When set to TOP, the two-line status appears near the
top of the display device screen. When set to CENTER, the two-line
status is centered on the display device screen. When set to
BOTTOM, the two-line status appears near the bottom of the display
device screen. Refer to page 2-19 for more information about the
two-line status.
FORMAT SECAM, PAL, NTSC
Controls the compatibility between the video input connectors, the
video switcher and the display device. Select the setting that is
compatible with the source components and display device.
Note:
The FORMAT parameter affects the composite and S-Video output
connectors. It does not affect the component video output connector.
BACKGROUND ON, OFF
Activates and deactivates the menu background. When set to ON,
on-screen display menus appear over a solid blue or gray background
(depending on the display device). When set to OFF, on-screen
display menus appear over the video input signal.
Note:
When the BACKGROUND parameter is set to OFF, the on-screen display
will disappear if the display device is using the component video output
connector.
REMOTE STATE ON, OFF
Controls the remote control command bank indicator that appears in
the on-screen display. When set to ON, a command bank indicator
appears in the top-right corner of the on-screen display to indicate
the last command bank from which the MC-8 received a command.
When set to OFF, no command bank indicator appears in the on-
screen display.
A “Z” appears when a command from the Zone 2 command bank
was received last. An “S” appears when a command from the Shift
command bank was received last. No letter appears when a
command from the Main Zone command bank was received last.
DISPLAYSSETUP ON-SCREEN DISPLAY POSITION
DISPLAYSSETUP ON-SCREEN DISPLAY FORMAT
DISPLAYSSETUP ON-SCREEN DISPLAY BACKGROUND
DISPLAYSSETUP ON-SCREEN DISPLAY REMOTE STATE
