MC-8 Mode Adjust
5-29
DTS 2-CHAN & DTS(-ES) 2-CHAN
These modes, recommended for recording purposes, send
downmixed 5.1-channel or 6.1-channel DTS-ES input signals to the
front speakers and subwoofer as 2-channel LOGIC 7-encoded output
signals.
See “Listening Mode Menu Option and Parameter Descriptions” on page 5-34 for
detailed descriptions.
5.1a BYPASS
• Designed for playback of 5.1-channel analog sources, such as
DVD-A or SACD players.
• Sends the 5.1-channel analog audio input connector directly to
the Main Zone volume control and audio output connectors, as
shown on pages 2-9 and 3-59. These signals receive no internal
processing.
• When both side and rear speakers are present, surround
channel signals are sent in parallel to the side and rear speakers.
To configure a 5-channel speaker setup, set the OUTPUT
LEVELS menu SIDE L/R or REAR L/R parameter to OFF to
deactivate the associated surround speakers.
• The 5.1a BYPASS listening mode is automatically activated
whenever the 5.1-channel analog audio input connector is
assigned to the selected input. The 5.1a BYPASS listening mode
is only available for 5.1-channel analog sources.
• Pressing the remote control SHIFT then 2CH buttons toggles
the MAIN ADV menu ANALOG BYPASS parameter between ON
and OFF.
Note:
Speaker crossover settings, speaker distances and audio (tone) controls
are not available when the 5.1a BYPASS listening mode is activated.
Option/Parameter Default Setting Possible Settings
CENTER MIX +0dB –25 to +5dB
SURROUND MIX +0dB –5 to +5dB
CNTR DLY SAMPLES +0 –127 to +127
MASTER LEVEL +0dB –5 to +5dB
LFE MIX +0.0dB –20.0 to +0.0dB
ES DECODING AUTO AUTO, ON, OFF
SUB LEVEL +0dB OFF, –30 to +12dB
CUSTOM Refer to page 5-32
2-CHAN
MODE ADJUST
OR
2-CHAN
Parameter Default Setting Possible Settings
OUTPUT LEVELS Refer to page 5-32
CUSTOM Refer to page 5-32
MODE ADJUST 5.1a BYPASS
