PERFORMING AUTOMATIC CALIBRATION (continued)
STEP DISTANCES DISTANCES & LEVELS LEVELS
3
This step does not occur when the AUTO
SPEAKER SETUP menu LEVELS option is
selected.
4
This step does not occur when the AUTO SPEAKER
SETUP menu DISTANCES option is selected.
CUSTOM SETUP
SETTING DISTANCES
FRONT LEFT
CENTER
FRONT RIGHT
SIDE RIGHT
REAR RIGHT
REAR LEFT
SIDE LEFT
SUBWOOFER
0.0ft
0.0ft
0.0ft
0.0ft
0.0ft
0.0ft
0.0ft
0.0ft
CUSTOM SETUP
SETTING DISTANCES
FRONT LEFT
CENTER
FRONT RIGHT
SIDE RIGHT
REAR RIGHT
REAR LEFT
SIDE LEFT
SUBWOOFER
12.0ft
10.5ft
12.0ft
4.5ft
ERROR
6.0ft
4.5ft
N/A
CUSTOM SETUP
SETTING LEVELS
FRONT LEFT
CENTER
FRONT RIGHT
SIDE RIGHT
REAR RIGHT
REAR LEFT
SIDE LEFT
SUBWOOFER
0.0dB
0.0dB
0.0dB
0.0dB
0.0dB
0.0dB
0.0dB
0.0dB
CUSTOM SETUP
SETTING LEVELS
FRONT LEFT
CENTER
FRONT RIGHT
SIDE RIGHT
REAR RIGHT
REAR LEFT
SIDE LEFT
SUBWOOFER
-2.0dB
ERROR
-2.0dB
-4.5dB
-3.0dB
-3.0dB
-4.5dB
N/A
The SETTING DISTANCES menu is displayed when the MC-8 calibrates speaker distances.
• During speaker distance calibration, the MC-8 sends calibration noise signals to the Main Zone
audio output connectors in the order shown on the SETTING DISTANCES menu. The cursor auto-
matically scrolls downward through speaker calibration parameters, highlighting each parameter
while the MC-8 calculates a distance for the corresponding speaker. As it finishes each parameter,
the MC-8 enters the calibrated value or an ERROR message to the right of the parameter label.
• Because of the way low-frequency signals propagate in most listening spaces, automatic speaker dis-
tance calibration often produces unreliable results for subwoofers. For this reason, the MC-8 does not
send calibration noise signals to the Subwoofer connector during speaker distance calibration. Instead,
the MC-8 automatically calibrates the subwoofer distance to the shortest distance of the other speak-
ers. These distances can be manually adjusted. See “PERFORMING MANUAL SPEAKER DISTANCE CAL-
IBRATION” on page 3-53.
The SETTING LEVELS menu is displayed when the MC-8 calibrates output levels.
• During speaker levels calibration, the MC-8 sends calibration noise signals to the Main Zone
audio output connectors in the order shown on the SETTING LEVELS menu. The cursor auto-
matically scrolls downward through speaker calibration parameters, highlighting each parame-
ter while the MC-8 calculates an output level for the corresponding speaker. As it finishes each
parameter, the MC-8 enters the calibrated value or an ERROR message to the right of the
parameter label.
