MC-8 Setup
3-49
STEP
DISTANCES
DISTANCES & LEVELS LEVELS
5
FRONT LEFT
OK
Refer to the table on page
3-50 for information about
all possible speaker calibra-
tion messages.
FRONT LEFT
OK
Refer to the table on page
3-50 for information about
all possible speaker calibra-
tion messages.
When the MC-8 is finished calibrating
speaker distances, the AUTO DISTANCES
screen is displayed, indicating the results
for each individual speaker.
• A value indicates that no errors occurred
during the calibration procedure.
• An ERROR message indicates that a value
was calculated, but at least one error
occurred during the calibration proce-
dure.
• Press the  or  arrow button to high-
light the speaker calibration parameter
you want. Then press the  button to
view more detailed results for the
selected speaker. A message similar to
the one shown above will display.
• Refer to the table on page 3-50 for infor-
mation about all possible speaker calibra-
tion messages.
When the MC-8 is finished calibrating
speaker distances and output levels, the
AUTO SPEAKER SETUP screen is displayed,
indicating the results for each calibration
procedure.
• An OK message indicates that no errors
occurred during the calibration proce-
dure.
• An ERROR message indicates that values
were calculated, but at least one error
occurred during calibration.
• Press the  or  arrow button to high-
light the desired calibration procedure.
DISTANCES displays the AUTO DIS-
TANCES screen shown in the left column
of this table.
LEVELS displays the AUTO LEVELS screen
shown in the right column of this table.
• Press the  arrow button to select this
procedure.
• Refer to the instructions in the appropri-
ate column to view more detailed results
for each individual speaker.
When the MC-8 is finished calibrating
output levels, the AUTO LEVELS screen is
displayed, indicating the results for each
individual speaker.
• A value indicates that no errors occurred
during the calibration procedure.
• An ERROR message indicates that a value
was calculated, but at least one error
occurred during the calibration proce-
dure.
•Press the or  arrow button to high-
light the desired speaker calibration
parameter. Then, press the  arrow
button to view more detailed results for
the selected speaker. A message similar
to the one shown above will display.
• Refer to the table on page 3-50 for infor-
mation about all possible speaker calibra-
tion messages.
AUTO SPEAKER SETUP
DISTANCES
LEVELS
AUTO VALUES APPLIED
PRESS TO VIEW
DETAILS
OK
ERROR
AUTO LEVELS
FRONT LEFT
CENTER
FRONT RIGHT
SIDE RIGHT
REAR RIGHT
REAR LEFT
SIDE LEFT
SUBWOOFER
-2.0dB
ERROR
-2.0dB
-4.5dB
-3.0dB
-3.0dB
-4.5dB
N/A
AUTO DISTANCES
FRONT LEFT
CENTER
FRONT RIGHT
SIDE RIGHT
REAR RIGHT
REAR LEFT
SIDE LEFT
SUBWOOFER
12.0ft
10.5ft
12.0ft
4.5ft
ERROR
6.0ft
4.5ft
N/A


