MACINTOSH
®
SOFTWARE
SETUP
You must consult the Software
Installation Guide packaged with the
software CD-ROMs inside the Omega
box to ensure the successful installation
of the recording software and USB
setup.
If you haven’t already installed the
your software, please do so before
continuing on to the next section.
Mac OS
A USB device must initialize itself with
the host computer to operate
correctly. The Omega Studio
comprises several devices (audio and
MIDI) and each of those must be
initialized. Some Apple
®
Mac
computers will not recognize all of
these devices if the Omega Studio is
powered on (and connected to the
USB port) before the computer is
turned on. The simplest way to avoid
problems is to either turn on the
Omega Studio or connect it to the USB
port after the computer is booted.
However, there is a way to fore a
reinitialization after the computer is
running.
1. Make sure you close any
applications which are using
the Omega Studio.
2. Press the Mic 1-2 USB Assign
button and the Line 3-4 USB
Assign button at the same time
and then release them
simultaneously. The blue USB
light will flash and after three
seconds the Omega Studio will
be properly initialized.
Software Setup
OMEGA
TM
15

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexicon OMEGA and is the answer not in the manual?

Lexicon OMEGA Specifications

General IconGeneral
Mic Preamps2
Bit Depth24-bit
Phantom PowerYes
Digital InputsS/PDIF
Power SupplyUSB bus power
A/D Resolution24-bit
Headphone Output1 x 1/4" TRS
Sample Rate48 kHz
Software IncludedLexicon Pantheon VST Reverb
Analog Inputs2 x XLR, 2 x 1/4" TRS
Analog Outputs2 x 1/4" TRS
