283–284 and 287–288 paper
jams
Covers, knobs, and handles located behind
finisher Door G
Cover, knob, or handle name
1
Cover G1
2
Cover G2
3
Knob G3
4
Cover G4
5
Cover G7
6
Knob G8
7
Handle G9
1 Open Door G.
2 Lift both Cover G1 levers, and then remove any jammed paper.
3 Move Cover G2 to the right, and then remove any jammed
paper.
Note: If the paper is jammed in the rollers, rotate Knob G3
counterclockwise.
4 Move Cover G4 down, and then remove any jammed paper.
5 Move Cover G7 to the left, and then remove any jammed paper.
6 Pull Handle G9 until the tray is completely open.
7 Lift the inside cover. If the paper is jammed in the rollers, rotate
Knob G8 clockwise, and then remove the jammed paper.
8 Close Door G.
9 Press .
284–286 paper jams
1 Open Door H.
