Lexmark CS417 - Page 20

3 Align the notch (1) on the memory card with the ridge (2) on the connector.
2 1
4 Push the memory card straight into the connector, and then push the card toward the controller board wall
until it clicks into place.
1
2
5 Close the controller board access cover.
Additional printer setup 20
