3 Squeeze, and then slide the length guide tab to the correct position for the size of the paper being loaded.
1
2
Note: Use the paper size indicators on the bottom of the tray to help position the guide.
4 Squeeze, and then slide the width guide tab to the correct position for the size of the paper being loaded.
2
1
Note: Use the paper size indicators on the bottom of the tray to help position the guides.
5 Flex the sheets back and forth to loosen them, and then fan them. Do not fold or crease the paper. Straighten
the edges on a level surface.
Loading paper and specialty media 33
