Lexmark CS417 User Manual

Use To
RGB Saturation
0–5
Adjust saturation in color outputs.
Note: 0 is the factory default setting.
Color Balance
Cyan
‑5 to 5
Magenta
‑5 to 5
Ye l l o w
‑5 to 5
Black
‑5 to 5
Reset Defaults
Adjust color in printed output by increasing or decreasing the amount of toner
being used for each color.
Note: 0 is the factory default setting.
Color Samples
sRGB Display
sRGB Vivid
Display—True Black
Vivid
O—RGB
US CMYK
Euro CMYK
Vivid CMYK
O—CMYK
Print sample pages for each of the RGB and CMYK color conversion tables used
in the printer.
Notes:
• Selecting any setting prints the sample.
• Color samples consist of a series of colored boxes along with the RGB or
CMYK combination that creates the color observed. These pages can be
used to help decide which combinations to use to get the printed output
you want.
• To access a complete list of color sample pages using the Embedded Web
Server, type the network printer IP address in the Web browser address
field.
Manual Color
RGB Image
RGB Text
RGB Graphics
Customize the RGB color conversions.
Select from the following options:
Vivid
sRGB Display
Display—True Black
sRGB Vivid
O
Notes:
• sRGB Display is the factory default setting for RGB Image. This applies a
color conversion table to an output that matches the colors displayed on a
computer monitor.
• sRGB Vivid is the factory default setting for RGB Text and RGB Graphics.
This applies a color table that increases saturation. This is preferred for
business graphics and text.
• Vivid applies a color conversion table that produces brighter, more
saturated colors.
• “Display—True Black” applies a color conversion table that uses only black
toner for neutral gray colors.
• O turns o color conversion.
Understanding the printer menus 91
