All life indicators are designed to function with Lexmark supplies and parts, and may deliver unpredictable
results if third-party supplies or parts are used. Imaging component usage beyond the intended life may
damage your Lexmark printer or its associated components.
Warning—Potential Damage: Use of third-party supplies or parts can aect warranty coverage.
Damage caused by the use of third-party supplies or parts may not be covered by the warranty.
To accept any and all of these risks, and to proceed with the use of non-genuine supplies or parts in your
printer, press
and on the control panel simultaneously for 15 seconds to clear the message and
continue printing.
If you do not want to accept these risks, then remove the third-party supply or part from your printer and
install a genuine Lexmark supply or part.
Note: For the list of supported supplies, see the “Ordering supplies” section or go to
www.lexmark.com.
Printer had to restart. Last job may be incomplete.
From the printer control panel, press to clear the message and continue printing.
For more information, go to
http://support.lexmark.com or contact customer support.
Reinstall missing or unresponsive [color] cartridge [31.xy]
Try one or more of the following:
Install the missing toner cartridge. For more information, see the “Replacing supplies” section of the
User’s Guide.
Remove the unresponsive cartridge, and then reinstall it.
Note: If the message appears after reinstalling the supply, then the cartridge may be defective.
Replace the cartridge.
Reinstall missing or unresponsive black and color imaging kit and all
cartridges [31.xy]
Try one or more of the following:
Check if the imaging kit is missing. If missing, then install the imaging kit.
For information on installing the imaging kit, see the “Replacing supplies” section.
If the imaging kit is installed, then remove and reinstall the unresponsive imaging kit.
Note: If the message appears after reinstalling the supply, then replace the imaging kit. The imaging
kit may be defective or a nongenuine Lexmark supply. For more information, see
“Using genuine
Lexmark parts and supplies” on page 110.
Troubleshooting 152

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark CS417dn and is the answer not in the manual?

Lexmark CS417dn Specifications

General IconGeneral
Internal memory256 MB
Processor cores2
Built-in processorYes
Noise level (idle)16 dB
Processor frequency800 MHz
Maximum internal memory2304 MB
Sound pressure level (printing)50 dB
Sound pressure level (duplex printing)52 dB
Wi-FiNo
Network ready-
Cabling technology10/100Base-T(X)
Security algorithmsSNMPv3
Ethernet LAN data rates10, 100 Mbit/s
Supported network protocols (IPv4)TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)TCP/IP IPv6, TCP, UDP
DisplayLCD
CertificationENERGY STAR, Blue Angel RAL-UZ-171, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, UCRF, EC 1275
Product colorGray
Display diagonal2.4 \
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)9 s
Time to first page (color, normal)10 s
Print speed (black, normal quality, A4/US Letter)30 ppm
Duplex print speed (black, normal quality, A4/US Letter)15 ppm
Country of originChina
Maximum duty cycle75000 pages per month
Recommended duty cycle800 - 6000 pages per month
Number of print cartridges5
Page description languagesMicrosoft XPS, PCL 5c, PCL 6, PDF 1.7, PPDS, PostScript 3
Power consumption (off)0.5 W
Power consumption (ready)30 W
Power consumption (standby)3 W
Power consumption (printing)580 W
Energy Star Typical Electricity Consumption (TEC)2.5 kWh/week
Total input capacity251 sheets
Total output capacity125 sheets
Maximum input capacity1451 sheets
Total number of input trays1
Maximum number of input trays4
Sustainability certificatesENERGY STAR
Other operating systems supportedHP-UX 11.11, HP-UX 11.23, HP-UX 11.31, IBM AIX 5.3, IBM AIX 6.1, IBM AIX 7.1, Novell Distributed Print Services (NDPS), Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server, Solaris 10, Solaris 10 SPARC, Solaris 11, Solaris 9 SPARC
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Paper tray media typesCard stock, Labels, Transparencies
Paper tray media weight60 - 176 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Universal, Legal (media size)
ISO A-series sizes (A0...A9)A4, A5
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Operating altitude0 - 2896 m
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Package depth495 mm
Package width595 mm
Package height402 mm
Package weight23800 g
Cables includedAC
Included cartridge capacity (CMY)750 pages
Included cartridge capacity (black)1400 pages
USB connectorUSB Type-A / USB Type-B
Standard interfacesEthernet, USB 2.0
Optional connectivityWireless LAN
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Weight and Dimensions IconWeight and Dimensions
Depth407 mm
Width442 mm
Height291 mm
Weight20500 g
