Lexmark CS417dn User Manual

Use To
Wiping Mode
Auto
Specify the mode for erasing temporary data files.
Automatic Method
Single pass
Multiple pass
Mark all disk space used by a previous print job. This method does not permit
the file system to reuse this space until it has been cleared.
Notes:
• “Single pass” is the factory default setting.
• Only automatic wiping enables users to erase temporary data
files
without having to turn o the printer for an extended amount of time.
• Highly
confidential
information should be erased using only the Multiple
pass method.
Security Audit Log menu
Use To
Export Log Let an authorized user export the audit log.
Notes:
• To export the audit log from the printer control panel, attach a flash drive
to the printer.
• The audit log can be downloaded from the Embedded Web Server and
saved on a computer.
Delete Log
Ye s
No
Specify whether or not audit logs are deleted.
Note: Yes is the factory default setting.
Configure Log
Enable Audit
Ye s
No
Enable Remote Syslog
No
Ye s
Remote Syslog Facility
0–23
Severity of Events to Log
0–7
Specify how and whether or not audit logs are created.
Notes:
• Enable Audit determines if events are recorded in the secure audit log
and remote syslog. No is the factory default setting.
• Enable Remote Syslog determines if logs are sent to a remote server. No
is the factory default setting.
• Remote Syslog Facility determines the value used to send logs to the
remote syslog server. 4 is the factory default setting.
• If the security audit log is activated, then the severity value of each event
is recorded. 4 is the factory default setting.
Set Date and Time menu
Use To
Current Date and Time View the current date and time settings for the printer.
Understanding the printer menus 80

Lexmark CS417dn Specifications

General

Internal memory	256 MB
Processor cores	2
Built-in processor	Yes
Noise level (idle)	16 dB
Processor frequency	800 MHz
Maximum internal memory	2304 MB
Sound pressure level (printing)	50 dB
Sound pressure level (duplex printing)	52 dB
Wi-Fi	No
Network ready	-
Cabling technology	10/100Base-T(X)
Security algorithms	SNMPv3
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)	TCP/IP IPv6, TCP, UDP
Display	LCD
Certification	ENERGY STAR, Blue Angel RAL-UZ-171, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, UCRF, EC 1275
Product color	Gray
Display diagonal	2.4 \
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Duplex print speed (black, normal quality, A4/US Letter)	15 ppm
Country of origin	China
Maximum duty cycle	75000 pages per month
Recommended duty cycle	800 - 6000 pages per month
Number of print cartridges	5
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PDF 1.7, PPDS, PostScript 3
Power consumption (off)	0.5 W
Power consumption (ready)	30 W
Power consumption (standby)	3 W
Power consumption (printing)	580 W
Energy Star Typical Electricity Consumption (TEC)	2.5 kWh/week
Total input capacity	251 sheets
Total output capacity	125 sheets
Maximum input capacity	1451 sheets
Total number of input trays	1
Maximum number of input trays	4
Sustainability certificates	ENERGY STAR
Other operating systems supported	HP-UX 11.11, HP-UX 11.23, HP-UX 11.31, IBM AIX 5.3, IBM AIX 6.1, IBM AIX 7.1, Novell Distributed Print Services (NDPS), Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server, Solaris 10, Solaris 10 SPARC, Solaris 11, Solaris 9 SPARC
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Paper tray media types	Card stock, Labels, Transparencies
Paper tray media weight	60 - 176 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Package depth	495 mm
Package width	595 mm
Package height	402 mm
Package weight	23800 g
Cables included	AC
Included cartridge capacity (CMY)	750 pages
Included cartridge capacity (black)	1400 pages
USB connector	USB Type-A / USB Type-B
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	407 mm
Width	442 mm
Height	291 mm
Weight	20500 g
