Lexmark CS417dn User Manual

PCL Emul menu
Use To
Font Source
Resident
Disk
Download
Flash
All
Specify the set of fonts used by the Font Name menu.
Notes:
• “Resident” is the factory default setting. Resident shows the factory
default set of fonts downloaded in the RAM.
• “Flash” and “Disk” settings show all fonts resident in that option.
• The flash option must be properly formatted and cannot be
read/write‑, write‑, or password‑protected.
• “Download” shows all the fonts downloaded in the RAM.
• “All” shows all fonts available to any option.
Font Name
Courier 10
Identify a specific font and the option where it is stored.
Note: Courier 10 is the factory default setting. Courier 10 shows the font
name, font ID, and the storage location in the printer. The font source
abbreviation is R for Resident, F for Flash, K for Disk, and D for
Download.
Symbol Set
10U PC‑8
12U PC‑850
Specify the symbol set for each font name.
Notes:
• 10U PC‑8 is the US factory default setting. 12U PC‑850 is the
international factory default setting.
• A symbol set is a set of alphabetic and numeric characters,
punctuation, and special symbols. Symbol sets support the dierent
languages or
specific
programs such as math symbols for
scientific
text. Only the supported symbol sets are shown.
PCL Emulation Settings
Point Size
1.00–1008.00
Change the point size for scalable typographic fonts.
Notes:
• 12 is the factory default setting.
• Point size refers to the height of the characters in the font. One point
equals approximately 0.014 inch.
• Point sizes can be increased or decreased in 0.25‑point increments.
PCL Emulation Settings
Pitch
0.08–100
Specify the font pitch for scalable monospaced fonts.
Notes:
• 10 is the factory default setting.
• Pitch refers to the number of fixed‑space characters per inch (cpi).
• Pitch can be increased or decreased in 0.01‑cpi increments.
• For nonscalable monospaced fonts, the pitch appears on the display
but it cannot be changed.
Understanding the printer menus 95

Lexmark CS417dn Specifications

General

Internal memory	256 MB
Processor cores	2
Built-in processor	Yes
Noise level (idle)	16 dB
Processor frequency	800 MHz
Maximum internal memory	2304 MB
Sound pressure level (printing)	50 dB
Sound pressure level (duplex printing)	52 dB
Wi-Fi	No
Network ready	-
Cabling technology	10/100Base-T(X)
Security algorithms	SNMPv3
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)	TCP/IP IPv6, TCP, UDP
Display	LCD
Certification	ENERGY STAR, Blue Angel RAL-UZ-171, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, UCRF, EC 1275
Product color	Gray
Display diagonal	2.4 \
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Duplex print speed (black, normal quality, A4/US Letter)	15 ppm
Country of origin	China
Maximum duty cycle	75000 pages per month
Recommended duty cycle	800 - 6000 pages per month
Number of print cartridges	5
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PDF 1.7, PPDS, PostScript 3
Power consumption (off)	0.5 W
Power consumption (ready)	30 W
Power consumption (standby)	3 W
Power consumption (printing)	580 W
Energy Star Typical Electricity Consumption (TEC)	2.5 kWh/week
Total input capacity	251 sheets
Total output capacity	125 sheets
Maximum input capacity	1451 sheets
Total number of input trays	1
Maximum number of input trays	4
Sustainability certificates	ENERGY STAR
Other operating systems supported	HP-UX 11.11, HP-UX 11.23, HP-UX 11.31, IBM AIX 5.3, IBM AIX 6.1, IBM AIX 7.1, Novell Distributed Print Services (NDPS), Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server, Solaris 10, Solaris 10 SPARC, Solaris 11, Solaris 9 SPARC
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Paper tray media types	Card stock, Labels, Transparencies
Paper tray media weight	60 - 176 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Package depth	495 mm
Package width	595 mm
Package height	402 mm
Package weight	23800 g
Cables included	AC
Included cartridge capacity (CMY)	750 pages
Included cartridge capacity (black)	1400 pages
USB connector	USB Type-A / USB Type-B
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	407 mm
Width	442 mm
Height	291 mm
Weight	20500 g
