Lexmark CS417dn User Manual

Object type Color conversion tables
RGB Image
RGB Text
RGB Graphics
• Vivid—Produces brighter, more saturated colors and may be
applied to all incoming color formats.
• sRGB Display—Produces an output that approximates the
colors displayed on a computer monitor.
Note: Black toner usage is optimized for printing photographs.
• Display‑True Black—Produces an output that approximates the
colors displayed on a computer monitor. This uses only black
toner to create all levels of neutral gray.
• sRGB Vivid—Provides an increased color saturation for the
sRGB Display color correction.
Note: Black toner usage is optimized for printing business
graphics.
• O—No color correction is implemented.
CMYK Image
CMYK Text
CMYK Graphics
• US CMYK—Applies color correction to approximate the SWOP
(Specifications
for Web
Oset
Publishing) color output.
• Euro CMYK—Applies color correction to approximate Euroscale
color output.
• Vivid CMYK—Increases the color saturation of the US CMYK
color correction setting.
• O—No color correction is implemented.
How can I match a particular color (such as a corporate logo)?
Nine types of Color Samples sets are available from the Quality menu on the printer control panel. These are
also available from the Color Samples page of the Embedded Web Server. Selecting any sample set
generates a multiple‑page printout consisting of hundreds of colored boxes. Either a CMYK or RGB
combination is located on each box, depending on the table selected. The observed color of each box is
obtained by passing the CMYK or RGB combination labeled on the box through the selected color conversion
table.
By examining Color Samples sets, you can identify the box whose color is the closest to the color you want.
The color combination labeled on the box can then be used for modifying the color of the object in a software
program. For more information, see the help information of your operating system.
Note: Manual color correction may be necessary to utilize the selected color conversion table for the
particular object.
Selecting which Color Samples set to use for a particular color‑matching problem depends on the Color
Correction setting being used , the type of object being printed, and how the color of the object is specified
in the software program. When Color Correction is set to O, the color is based on the print job information,
and no color conversion is implemented.
Note: The Color Samples pages are not useful if the software program does not specify colors with RGB or
CMYK combinations. Additionally, certain situations exist in which the software program or the computer
operating system adjusts the RGB or CMYK combinations specified in the program through color
management. The resulting printed color may not be an exact match of the Color Samples pages.
Troubleshooting 188

Lexmark CS417dn Specifications

General

Internal memory	256 MB
Processor cores	2
Built-in processor	Yes
Noise level (idle)	16 dB
Processor frequency	800 MHz
Maximum internal memory	2304 MB
Sound pressure level (printing)	50 dB
Sound pressure level (duplex printing)	52 dB
Wi-Fi	No
Network ready	-
Cabling technology	10/100Base-T(X)
Security algorithms	SNMPv3
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)	TCP/IP IPv6, TCP, UDP
Display	LCD
Certification	ENERGY STAR, Blue Angel RAL-UZ-171, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, UCRF, EC 1275
Product color	Gray
Display diagonal	2.4 \
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Duplex print speed (black, normal quality, A4/US Letter)	15 ppm
Country of origin	China
Maximum duty cycle	75000 pages per month
Recommended duty cycle	800 - 6000 pages per month
Number of print cartridges	5
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PDF 1.7, PPDS, PostScript 3
Power consumption (off)	0.5 W
Power consumption (ready)	30 W
Power consumption (standby)	3 W
Power consumption (printing)	580 W
Energy Star Typical Electricity Consumption (TEC)	2.5 kWh/week
Total input capacity	251 sheets
Total output capacity	125 sheets
Maximum input capacity	1451 sheets
Total number of input trays	1
Maximum number of input trays	4
Sustainability certificates	ENERGY STAR
Other operating systems supported	HP-UX 11.11, HP-UX 11.23, HP-UX 11.31, IBM AIX 5.3, IBM AIX 6.1, IBM AIX 7.1, Novell Distributed Print Services (NDPS), Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server, Solaris 10, Solaris 10 SPARC, Solaris 11, Solaris 9 SPARC
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Paper tray media types	Card stock, Labels, Transparencies
Paper tray media weight	60 - 176 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Package depth	495 mm
Package width	595 mm
Package height	402 mm
Package weight	23800 g
Cables included	AC
Included cartridge capacity (CMY)	750 pages
Included cartridge capacity (black)	1400 pages
USB connector	USB Type-A / USB Type-B
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	407 mm
Width	442 mm
Height	291 mm
Weight	20500 g
