Lexmark CS417dn User Manual

Use To
RGB Saturation
0–5
Adjust saturation in color outputs.
Note: 0 is the factory default setting.
Color Balance
Cyan
‑5 to 5
Magenta
‑5 to 5
Ye l l o w
‑5 to 5
Black
‑5 to 5
Reset Defaults
Adjust color in printed output by increasing or decreasing the amount of toner
being used for each color.
Note: 0 is the factory default setting.
Color Samples
sRGB Display
sRGB Vivid
Display—True Black
Vivid
O—RGB
US CMYK
Euro CMYK
Vivid CMYK
O—CMYK
Print sample pages for each of the RGB and CMYK color conversion tables used
in the printer.
Notes:
• Selecting any setting prints the sample.
• Color samples consist of a series of colored boxes along with the RGB or
CMYK combination that creates the color observed. These pages can be
used to help decide which combinations to use to get the printed output
you want.
• To access a complete list of color sample pages using the Embedded Web
Server, type the network printer IP address in the Web browser address
field.
Manual Color
RGB Image
RGB Text
RGB Graphics
Customize the RGB color conversions.
Select from the following options:
Vivid
sRGB Display
Display—True Black
sRGB Vivid
O
Notes:
• sRGB Display is the factory default setting for RGB Image. This applies a
color conversion table to an output that matches the colors displayed on a
computer monitor.
• sRGB Vivid is the factory default setting for RGB Text and RGB Graphics.
This applies a color table that increases saturation. This is preferred for
business graphics and text.
• Vivid applies a color conversion table that produces brighter, more
saturated colors.
• “Display—True Black” applies a color conversion table that uses only black
toner for neutral gray colors.
• O turns o color conversion.
Understanding the printer menus 92

Lexmark CS417dn Specifications

General

Internal memory	256 MB
Processor cores	2
Built-in processor	Yes
Noise level (idle)	16 dB
Processor frequency	800 MHz
Maximum internal memory	2304 MB
Sound pressure level (printing)	50 dB
Sound pressure level (duplex printing)	52 dB
Wi-Fi	No
Network ready	-
Cabling technology	10/100Base-T(X)
Security algorithms	SNMPv3
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk
Supported network protocols (IPv6)	TCP/IP IPv6, TCP, UDP
Display	LCD
Certification	ENERGY STAR, Blue Angel RAL-UZ-171, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, UCRF, EC 1275
Product color	Gray
Display diagonal	2.4 \
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Duplex print speed (black, normal quality, A4/US Letter)	15 ppm
Country of origin	China
Maximum duty cycle	75000 pages per month
Recommended duty cycle	800 - 6000 pages per month
Number of print cartridges	5
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PDF 1.7, PPDS, PostScript 3
Power consumption (off)	0.5 W
Power consumption (ready)	30 W
Power consumption (standby)	3 W
Power consumption (printing)	580 W
Energy Star Typical Electricity Consumption (TEC)	2.5 kWh/week
Total input capacity	251 sheets
Total output capacity	125 sheets
Maximum input capacity	1451 sheets
Total number of input trays	1
Maximum number of input trays	4
Sustainability certificates	ENERGY STAR
Other operating systems supported	HP-UX 11.11, HP-UX 11.23, HP-UX 11.31, IBM AIX 5.3, IBM AIX 6.1, IBM AIX 7.1, Novell Distributed Print Services (NDPS), Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server, Solaris 10, Solaris 10 SPARC, Solaris 11, Solaris 9 SPARC
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Paper tray media types	Card stock, Labels, Transparencies
Paper tray media weight	60 - 176 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Package depth	495 mm
Package width	595 mm
Package height	402 mm
Package weight	23800 g
Cables included	AC
Included cartridge capacity (CMY)	750 pages
Included cartridge capacity (black)	1400 pages
USB connector	USB Type-A / USB Type-B
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	407 mm
Width	442 mm
Height	291 mm
Weight	20500 g
