Lexmark MS621 - Page 210

4 Hold the end of the shaft (D), and then pull out the roller to remove it.
C D
5 Remove the two E‑clips (A).
A
A
6 Move the roller (B) to the left, and then remove the pin (C).
4600-830, -835, -895
Parts removal
210
