Lexmark MX417 - UICC Removal; UICC (MX310) Removal

UICC removal
1 Remove the control panel assembly. See “Control panel assembly removal” on page 315.
2 Disconnect the video cable (A) from the UICC.
A
3 Remove the
five
screws, and then remove the UICC.
UICC (MX310) removal
1 Remove the control panel assembly. See “Control panel assembly removal” on page 315.
2 Place the control panel assembly facedown on a non‑marring surface.
3 Remove the five screws (A) from the UICC.
A
7015
Parts removal
318
