Assembly 5: Electronics 3
Asm-index P/N Units/mach Units/FRU Description Removal procedure
141X1988 1 1Sensor (cartridge
barrel)
“Cartridge barrel shutter sensor kit
removal” on page 249
2 41X1162 1 1 Toner cartridge smart
chip contact
“Toner cartridge smart chip contact
removal” on page 247
3 41X2274 1 1 Sensor (bin full)
“Sensor (bin full) removal” on page 301
4 41X1209 1 1 Sensor (front door)
“Sensor (front door) removal” on
page 265
5 41X1236 1 1 Interconnect cable
“Interconnect cable removal” on
page 240
6 41X1238 1 1 Sensor (tray present)
“Sensor (tray present) removal” on
page 242
7 41X1210 1 1 Sensor (MPF paper
present)
“Sensor (MPF paper present) removal”
on page 270
7018
Parts catalog
398
