3 Remove the ADF lift tray. See “ADF lift tray removal” on page 594.
4 Remove the input tray. See “ADF input tray removal” on page 589.
5 Remove the JELEV1 cable (A) from the ADF controller card.
6 Remove the three screws (B) and the c-clip (C) on the rear of the ADF tray lift drive.
7463
Repair information
609
