8
4
Attach the operator panel overlay.
If English is not your preferred language, attach the
overlay with the appropriately translated names for
the operator panel.
a Peel the protective backing off the overlay.
b Align the holes in the overlay with the buttons on
the operator panel and press it into place.
c Rub the overlay firmly to make sure it adheres
securely to the operator panel.
d Peel the protective covering away from the over-
lay.
5 Attach the paper bail.
a Remove the printer top cover and slide the plas-
tic bracket onto the static brush holder. Adjust
the bracket so it is centered over the area where
paper exits.
b Place the tips of the wire paper bail into the ends
of the plastic bracket so that the bail curves
downward.
c Replace the top cover.
Operator panel
overlay
To Next Page
