18
Step 4: Attach cables
You can attach your printer to a network or locally (directly
to a computer).
Network printing You can attach your printer to a network using standard
network cables.
A 10BaseT/100BaseTX Fast Ethernet port is standard on
the Lexmark T522 printer. You can add a Token-Ring or
10Base2 Ethernet port by installing an optional MarkNet
internal print server.
To attach the printer to a network:
1 Make sure the printer, computer, and any other
attached devices are turned off and unplugged.
2 Connect the printer to a LAN drop or hub using
standard cabling that is compatible with your
network.
The printer automatically adjusts itself for the net-
work speed.
– Token-Ring, Ethernet 10BaseT, or Ethernet
100BaseTX networks (Category 5) use an
RJ-45 connector.
