15
3
Remove and save the two screws on the back of the
printer that attach the metal plate to the slot.
Remove and discard the plate.
4 Unpack the card. Save the packaging materials.
5 Align the connection points on the card with the
connector on the system board and push the card
firmly into the system board connector.
6 Insert the two screws saved from the metal plate (or
the extra screws shipped with the card) into the
holes.
7 Tighten the screws to secure the card.
