Lexmark XC2130 Service Manual

Parts catalog
• “Legend” on page 392
• “Assembly 1: Covers” on page 393
• “Assembly 2: Scanner” on page 395
• “Assembly 3: Paper path” on page 397
• “Assembly 4: Operator panels” on page 401
• “Assembly 5: Electronics” on page 405
• “Assembly 6: Cables and sensors” on page 409
• “Assembly 7: Media drawers and trays” on page 411
• “Assembly 8: Options and miscellaneous” on page 413
Legend
The following column headings are used in the parts catalog:
• ASM‑index
—Identifies
the assembly and the item in the diagram. For example, 3‑1 indicates Assembly 3
and item 1 in the table.
• Part number
—Identifies
the unique number that correlates with the part.
• Units/mach—Refers to the number of units actually used in the base machine or product.
• Units/option—Refers to the number of units in a particular option.
• Units/FRU—Refers to the number of units in a particular FRU.
• Description—A brief description of the part.
The following abbreviations are used in the parts catalog:
• NS (not shown) in the Asm‑index column indicates that the part is procurable but is not pictured in the
illustration.
• PP (parts packet) in the Description column indicates that the part is contained in a parts packet.
7527
Parts catalog
392
www MK-Electronic de

Lexmark XC2130 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	10.5 s
Time to first page (color, normal)	11.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Copier resize	25 - 400 %
Time to first copy (black, normal)	10.8 s
Time to first copy (color, normal)	11.6 s
Copy speed (black, normal quality, A4)	30 cpm
Scanner type	Flatbed & ADF scanner
Duplex scanning	Yes
Duplex scan speed (color)	13 ppm
Optical scanning resolution	600 x 1200 DPI
Faxing	Color faxing
Modem speed	33.6 Kbit/s
Digital sender	-
Maximum duty cycle	- pages per month
Recommended duty cycle	800 - 6000 pages per month
Card reader integrated	No
Maximum internal memory	2560 MB
Sound pressure level (copying)	50 dB
Sound pressure level (printing)	49 dB
Paper input type	Paper tray
Total input capacity	251 sheets
Total output capacity	150 sheets
Maximum input capacity	1451 sheets
Auto document feeder (ADF) input capacity	50 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Control type	Touch
Product color	White
Display diagonal	4.3 \
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %

Weight and Dimensions

Depth	558 mm
Width	444 mm
Height	470 mm
