267
2-4. Using other driving systems
2
When driving
LS460_EE
The distance display and buzzer
When a sensor detects an obstacle, the direction of and the approx-
imate distance to the obstacle are displayed and the buzzer sounds.
Center sensors
Corner sensors and side sensors
Level 1 2 3 4
Display
example of
front center
sensor
Buzzer Slow Medium Fast Continuous
Level 1 2 3 4
Display
example of
front right
sensor
-
Buzzer - Medium Fast Continuous
To Next Page
