ELECTRICAL COMPONENTS
290
2001 MY RX300_U (OM48431U)
No.
FUSE
AMPERE
CIRCUIT
18
ABS 3 7.5 Anti–lock brake system
19
H–LP R
UPR
15
Right–hand headlight
(high beam)
20
H–LP L
UPR
15
Left–hand headlight
(high beam)
21
A/F HTR 25 Air fuel ratio sensor
22
IGN 7.5
SRS system, Multiport fuel
injection/Sequential multiport
fuel injection system
23
RADIO
NO.2
7.5
Audio system, Multiplex
computer
24
CIG 15
Cigarette lighter, Outside rear
view mirrors, Power door lock
system
25
D RR
DOOR
20
Rear door lock, Rear power
window
26
PWR
OUTLET
15
Power outlets
27
FR FOG 15 Fog lights
28
SRS–IG 15 SRS system
29
ECU–IG 15
Telephone, Inside rear view
mirror, Anti–lock brake system,
Traction control system,
Multi–display
30
WIPER 25 Windshield wipers
No.
FUSE
AMPERE
CIRCUIT
31
P RR
DOOR
20
Rear door lock, Rear power
window
32
P FR
DOOR
20
Front door lock, Front power
window
33
S/ROOF 20 Moon roof
34
HEATER 15 Air conditioning system
35
GAUGE 7.5
Multiplex computer, Service
reminder indicators
36
RR WIP 15 Rear window wiper
37
STOP 20
Stop lights, High mounted
stoplight, Anti–lock brake
system, Traction control system
38
OBD 7.5 On–board diagnosis system
39
SEAT HTR 15 Seat heater system
40
STARTER 7.5 Starting system
41
WASHER 20 Washer
42
RR FOG 7.5 No circuit
43
FR DEF 20
Rear window and outside rear
view mirror defogger
44
TAIL 10
Tail lights, Side marker lights,
License plate lights, Parking
lights
45
PANEL 7.5 Instrument panel lights
46
ABS 60 Anti–lock brake system
47
ALT 140 Charging system
