LEYBOLD LEYSPEC view Series Quick Start Manual

9 300781309_002_C0 - 01/2019 - © Leybold
Part name and component function
The following table shows the settings before shipment from the factory.
LEYSPEC view100S/200S & LEYSPEC ultra 200S/300S
LEYSPEC view100/200
No. Function
1 To change IP address between “Fixed IP address” or “Automatic IP
address".
ON = automatic
OFF = fixed
2 Can be changed with power on and measurement stopped.
To select between secondary electron multiplier (SEM) or Faraday Cup
(FC).
ON = SEM
OFF = FC
3Not used.
4 Can be changed with power on and measurement stopped. To set local
and remote operation.
ON = Local mode (control panel operation only).
OFF = Remote mode (PC operation)
5
To set the sensor address for this LEYSPEC Residual Gas Analysers unit.
See the table below for switch settings.
6
7
8
AddressS5 S6S7S8 AddressS5 S6 S7 S8
1 0 001 9 1 0 0 1
2 0010 10 1010
3 0011 11 1011
4 0100 12 1100
5 0101 13 1101
6 0110 14 1110
7 0111 15 1111
8 1000 16 0000
S1 S2 S3 S4 S5 S6 S7 S8
OFF ON OFF OFF OFF OFF OFF ON
S1 S2 S3 S4 S5 S6 S7 S8
OFF OFF OFF OFF OFF OFF OFF ON
