PARTS FOR FEATHER BOARD DESCRIPTION QUANTITY
Feather board 3
M6x35 bolt, washer and wing nut for attaching
the feathers to the fence
4
M6x35 bolt, 2 washers and wing nut for attaching
the feather to the table top
2
OTHER PARTS FOR ASSEMBLY DESCRIPTION QUANTITY
Miter-gauge assembly 1
Starter pin 1
Tabletop insert with 1-1/4-in. diameter hole 1
Tabletop insert with 1-7/8-in. diameter hole 1
Tabletop insert with 2-1/8-in. diameter hole 1
‘Z’ Wrench 1
Part list for the router
PARTS FOR ROUTER DESCRIPTION QUANTITY
Router 1
Dust collection with vacuum adaptor and 2 screws 1
Chip guard (assembled to the router) 1
1/4 in. collet sleeve 1
Open-end wrench 1
Heavy-duty edge guide 1
TOOLS NEEDED
The following tools (not included) are needed for assembly or making adjustments.
Phillips Screwdriver
8 Open-end Wrench
