Step 1: Attach Lid Handle and Temperature
Gauge
Attach the lid handle (D) and lid handle supports
(E) onto the lid (A) with two M6 x 12 screws (DD),
two Ø6 washers (KK) and two Ø6 lock washers
(NN).
Attach temperature gauge (C) onto the lid (A).
NOTE
: Remove the washer and wing nut pre-
Hardware Used
1
2
D
E
E
A
A
F
F
C
Step 2: Attach Top Hinges
Attach the top hinges (F) onto the lid (A) with four
M5 x 12 bolts (BB), four M5 nuts (GG), four Ø5
washers (JJ) and four Ø5 lock washers (MM).
Hardware Used
ASSEMBLY INSTRUCTIONS
M6 x 12
Screw
DD
KK
NN
BB
GG
JJ
MM
x 2
Ø5
Lock
Washer
x 4
Ø6
Washer
x 2
M5 x 12
Bolt
x 4
Ø5
Washer
x 4
M5
Nut
x 4
Ø6
Lock
Washer
x 2
To Next Page
