65
Lower Drift Pin Assembly Timing Rod Runner Bolt
Tools and Materials Needed
• Set of metric Allen keys with ball ends
• 17 mm and 30 mm wrenches
• New Lower Drift Pin Assembly Rod Runner Bolt part
• Disposable latex/rubber gloves (for food grade products and to protect hands from grease)
• Hairnet and/or beard net (food grade products only)
• Sterile shoe covers (food grade products only)
The Lower Drift Pin Assembly Timing Rod's Runner Bolt can be damaged due to overtightening
and/or being under too much pressure.
Remove the Lower Drift Pin Assembly Runner Bolt
1. Remove the Hopper carefully and catch any powder still inside of it.
2. Remove the Ejection Tray with an Allen key.
Instructions
Note: Wear latex/rubber gloves (and appropriate food grade attire if applicable) during this process.
WARNING: To prevent any potential personal injury, ALWAYS unplug the TDP
5® from the electrical outlet when replacing parts.
To Next Page
