TDP 5® Parts List
1. TDP 5® Base (#AEC0000)
2. Lower Drift Pin Assembly Cogs (#AEC0012)
3. Lower Drift Pin Assembly Locking Bar (#AEC0013)
4. Lower Drift Pin Assembly Lifting Bar (#AEC0034)
5. Lower Drift Pin Assembly (#AEC0011)
6. Boot Bolt and Spring (inside Boot) (#AEC0051; #AEC0055)
7. Base Plate (#AEC0008)
8. Ejection Guard (#AEC0009)
9. Boot (#AEC0036)
10. Boot Timing Bar (#AEC0018)
11. Upper Drift Pin Assembly Mounting Block (#AEC0010)
12. Upper Drift Pin Assembly (#AEC0002)
13. Upper Drift Pin Assembly Locking Nut (#AEC0006)
14. Upper Drift Pin Assembly Threaded Cam (#AEC0005)
15. Boot Timing Cam (#AEC0038)
16. Hand Wheel (#AEC0046)
17. Top Cam (#AEC0037)
18. Eccentric Sheave (#AEC0033)
19. Eccentric Sheave Strap (#AEC0004)
20. Cam Drive Cog (inside Cam Drive Cog Safety Cover)
(#AEC0050)
21. Electrical Drive Flywheel (#AEC0021)
22. Pinion Gear (#AEC0022)
23. Lower Drift Pin Assembly Timing Rod Runner Bolt (#AEC0015)
24. Lower Drift Pin Assembly Timing Rod (#AEC0014)
25. V Belt (Drive Belt) (#H108012028)
26. Motor (#AEC0042)
27. Electrical Box and Connecting Cables (#AEC0053)
28. Motor Mounting Plate (#AEC0041)
29. Hopper (#AEC0030)
