5
3.1 MAIN FEATURES
4.1 PAIR THE OUTDOOR REMOTE SENSORS
• Temperature & Humidity measurement.
• Low Battery Indication.
3.2 TX BUTTONS ON THE BACK
1
2
3 OUTDOOR TEMPERATURE & HUMIDITY SENSOR STATION
RF Channel Selection.
Battery Compartment for 2 x AAA, 1.5V batteries.
1
2
4 FIRST TIME TO USE
First of all, it needs to do the pairing between outdoor remote sensors and
weather station. Please follow below procedure to pair the sensors.
1). Plug the included AC-AC adaptor into the weather station. (optional) insert 2
new “AAA”alkaline batteries for backup.
The screen is turned on. It starts to search sensors and register the received
sensors. During RF pairing, the signal strength icon will animate until the
sensors signal is received or for 5 minutes if no signal available.
