Installing Wall Mount Plate
This monitor meets the specifications for the wall mount plate or other compatible devices.
1 Place the screen face down. To protect the screen from scratches, cover the surface with the box's
monitor protection pad or a soft cloth.
2 Remove the four screws placed in the back of the monitor.
3 Align the wall mount plate with the screw holes and place it over the monitor.
4 Tighten the four screws to fix the plate to the monitor using a screwdriver.
NOTE
• The wall mount plate is sold separately.
• For more information on installation, refer to the wall mount plate's installation guide.
• Be careful not to apply too much force while mounting the wall mount plate as it may cause damage
to the screen
Installing on the Wall
Install the monitor at least 100 mm away from the wall to ensure sufficient ventilation. Detailed
installation instructions can be obtained from your local dealership. Please refer to the manual to install
and set up a tilting wall mount plate.
100 mm
100 mm
100 mm
100 mm
To install the monitor to a wall, attach a wall mount plate (optional) to the back of the monitor.
Make sure that the wall mount plate (optional) is securely fixed to the monitor and to the wall.
1 If you use screws longer than the standard length, it may damage the inside of the product.
2 A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is
not liable for any accidents relating to the use of non-standard screws.
