- 17 -
3. No RASTER on PC Signal
Repeat [A, B]
process.
Pass
Check the input/
output of R735,
R736.
Fail
Check the J701.
Pass
Re-soldering or change the
defect part, Check the X100.
Check
the input/output
of R128, R131,
R136.
Pass
Check the
input/output of IC100.
Pass
Check input source cable and jack.
Fail
Fail
Re-soldering or Change
the defect part.
