LG 20LS2R - Exploded View

- 23 -
EXPLODED VIEW PARTS LIST
No. PART NO. DESCRIPTION
EAB30826701 Speaker,Full Range EN1527C-6603-1. ND 7W 8OHM 80DB 170HZ 71.5 X 42 X 29.5 LUG
6304FAU027A LCD,Module-TFT T200XW02-V0 T200XW02-V0 AU TN,450NITS,600 BY 1,8MS, ROHS, 3H
ABJ31730602 Cabinet Assembly 20LS2R LP-69A 20” CABINET ASSY
ACQ31730702 Cover Assembly,Rear 20LS2R LP-69A 20” BACK COVER ASSY(EU_CKD)
ADV31731102 Frame Assembly 20LS2R LP-69A 20” REAR SHIELD ASSY
AAN30637910 Base Assembly STAND 20LS2R CL81 20LS2 BASE _NON_METAL(CSKD)
AAN31023102 Base Assembly STAND 20LS1R CL81 20LS1R STAND BODY ASSY’ , “A”-CSKD
MCK30214205 Cover MOLD HIPS 51SF 15LS1R HIPS 51SF 20/15 LS1R STAND BODY COVER, BK
EBU34016301 Main Total Assembly 20LS2R BRAND LP69A
EBR33871901 PCB Assembly,Sub CONTROL T.T LP69A 20LS2R AEUWLAX 20LS2R CONTOL T.T ASS’Y
MEY30552602 Knob, MOLD AB HF-380NB SUB CONTROL KNOB LS2R
EAY32636402 Power Supply Assembly AIV-P0033 FREE 20LS2R LCD 20.1 INCH 16:9 WIDE 6 LAMP LIPS
EBR33877501 PCB Assembly,Sub SUB T.T LP69A 20LS2R/23LS2R AEUWLAX/AEUULAX LS2 IR
MES32968101 Indicator MOLD PMMA LED 20/23LS2R PMMA 10 PHY LENS
120
200
300
400
410
430
431
432
520
530
531
580
590
591
