LG 20LS2R - Replacement Parts List

- 24 -
DATE: 2006. 12. 28.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C1001 0CC331CK41A C1608C0G1H331JT 330pF 5% 50V
C1002 0CC331CK41A C1608C0G1H331JT 330pF 5% 50V
C1003 0CC331CK41A C1608C0G1H331JT 330pF 5% 50V
C1004 0CC331CK41A C1608C0G1H331JT 330pF 5% 50V
C1005 0CC561CK41A C1608C0G1H561JT 560pF 5% 50V
C1006 0CC561CK41A C1608C0G1H561JT 560pF 5% 50V
C1007 0CC331CK41A C1608C0G1H331JT 330pF 5% 50V
C1008 0CC561CK41A C1608C0G1H561JT 560pF 5% 50V
C1009 0CC331CK41A C1608C0G1H331JT 330pF 5% 50V
C101 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1010 0CC331CK41A C1608C0G1H331JT 330pF 5% 50V
C1011 0CC561CK41A C1608C0G1H561JT 560pF 5% 50V
C1012 0CK105CD56A C1608X7R1A105KT 1uF 10% 10V
C1013 0CK105CD56A C1608X7R1A105KT 1uF 10% 10V
C102 0CH3224K946 C2012Y5V1H224ZT 220nF -20TO+
C103 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C104 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C105 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C106 0CC200CK41A C1608C0G1H200JT 20pF 5% 50V
C107 0CC200CK41A C1608C0G1H200JT 20pF 5% 50V
C108 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16V
C110 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16V
C1100 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C1101 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C1102 0CK105DH56A C2012X7R105KFT 1uF 10% 25V X
C1103 0CK105DH56A C2012X7R105KFT 1uF 10% 25V X
C1104 0CE477EF638 KMG5.0TP16VB470M 470uF 20% 1
C1105 0CE477EK618 KMG5.0TP50VB470M 470uF 20% 5
C1106 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1107 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C1109 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1110 0CK474DH56A C2012X7R1E474KT 470nF 10% 25
C1111 0CK474DH56A C2012X7R1E474KT 470nF 10% 25
C1112 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C1113 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C1114 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1116 0CK272CK46A 0603B272J500CT 2.7nF 10% 50V
C1117 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1118 0CK272CK46A 0603B272J500CT 2.7nF 10% 50V
C1119 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C112 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1120 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C1121 0CK226FF67A EMK325BJ226MM-T 22uF 20% 16V
C1122 0CK226FF67A EMK325BJ226MM-T 22uF 20% 16V
C1123 0CE227WF6DC MVK8.0TP16VC220M 220uF 20% 1
C1124 0CE477EH618 KMG5.0TP25VB470M 470uF 20% 2
C1125 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C1126 0CE107WH6DC MVK8.0TP25VC100M 100uF 20% 2
C1127 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1128 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1129 0CK105DH56A C2012X7R105KFT 1uF 10% 25V X
C1130 0CK105CD56A C1608X7R1A105KT 1uF 10% 10V
DATE: 2006. 12. 28.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C1131 0CK225DFK4A C2012Y5V1C225MT 2.2uF 20% 16
C1133 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1138 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C114 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1140 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C1141 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C116 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C117 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C118 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C119 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16V
C121 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C122 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C123 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C
C124 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C125 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C126 0CC560CK41A C1608C0G1H560JT 56pF 5% 50V
C127 0CC560CK41A C1608C0G1H560JT 56pF 5% 50V
C128 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C129 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C130 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C131 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C132 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C133 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C134 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C135 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C136 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C137 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C138 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C139 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C140 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C141 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C
C142 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C143 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C144 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C145 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C146 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C147 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C148 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C149 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C150 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C151 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C152 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C153 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C154 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C155 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C156 0CK473CK56A C1608X7R1H473KT 47nF 10% 50V
C157 0CC561CK41A C1608C0G1H561JT 560pF 5% 50V
C158 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C159 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16V
C160 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C161 0CC561CK41A C1608C0G1H561JT 560pF 5% 50V
C162 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C163 0CK475CC94A C1608Y5V0J475ZT 4.7uF -20TO+
C164 0CK105CD56A C1608X7R1A105KT 1uF 10% 10V
REPLACEMENT PARTS LIST
MAIN BOARD
CAPACITOR
For Capacitor & Resistors, the
charactors at 2nd and 3rd digit in the
P/No. means as follows;
CC, CX, CK, CN, CH : Ceramic
CQ : Polyestor
CE : Electrolytic
CF : Fixed Film
RD : Carbon Film
RS : Metal Oxide Film
RN : Metal Film
RH : CHIP, Metal Glazed(Chip)
RR : Drawing
