ASSEMBLING AND PREPARING
Detaching the Stand Base
1
Place the Monitor set with the screen side
down on a flat and cushioned surface.
Stand Base
Stand Base
Stand Body
Stand Body
Pull out the Stand Body and Stand Base
from the monitor set.
Turn the screw to the left with a coin.
Pull out the Stand Base.
1
2
3
2
27EA53VQ
Turn the screw to the left with a coin.
Pull out the Stand Base from the Stand Body.
Remove two screws and pull out the Stand
Body from the monitor set.
1
2
3
Stand Base
Stand Body
Stand Body
y
This illustration depicts the general model of
connection. Your monitor may differ from the
items shown in the picture.
y
Do not carry the product upside down holding
only the stand base. The product may fall
and get damaged or injure your foot.
CAUTION
22EA53VQ/23EA53VQ/24EA53VQ
