LG 22EA53T-P User Manual

www.lg.com
OWNER’S MANUAL
LED LCD MONITOR
22EA53T
23EA53T
24EA53T
Please read this manual carefully before operating
your set and retain it for future reference.
LED LCD MONITOR MODEL
ENGLISH

LG 22EA53T-P Specifications

General

3D	No
Pixel pitch	0.2745 x 0.274 mm
Aspect ratio	16:9
Display surface	-
Display diagonal	21.5 \
Display technology	LED
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 83 kHz
Contrast ratio (dynamic)	5000000:1
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	720 x 400, 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
HDCP	Yes
HDMI ports quantity	0
Product color	Black
Tilt angle range	-5 - 20 °
Panel mounting interface	75 x 75 mm
AC input voltage	100 - 240 V
Power consumption (standby)	0.3 W
Power consumption (typical)	25 W
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Package depth	98 mm
Package width	567 mm
Package height	371 mm

Weight and Dimensions

Depth (with stand)	181 mm
Height (with stand)	385 mm
Weight (with stand)	2800 g
Depth (without stand)	55 mm
Width (without stand)	508 mm
Height (without stand)	312 mm
Weight (without stand)	- g

Summary

Assembling and Preparing the Monitor

Unpacking Monitor Components

Check product box for included items and accessories.

Parts and Buttons Overview

Identifies monitor components, buttons, and connection panel.

Attaching and Detaching Stand Base

Instructions for assembling and disassembling the monitor stand base.

Table Mounting and Cable Management

Guides for placing the monitor on a table and organizing cables.

Kensington Security System Installation

Information on installing and using the Kensington security system.

Wall Mounting Preparations

Guidelines and VESA compatibility for mounting the monitor on a wall.

Using the Monitor Set

Connecting to a PC

Explains PC connection methods and Plug & Play support.

D-SUB Connection Guide

Details connecting the monitor using a D-SUB analog signal cable.

DVI-D Connection Guide

Details connecting the monitor using a DVI-D digital signal cable.

Customizing Monitor Settings

Monitor Set Buttons and OSD Navigation

Explains the functions of monitor buttons and OSD menu navigation.

General Menu Settings

Overview of basic settings like Brightness, Contrast, and Reset.

Picture Settings

Adjusting screen clearness and sharpness for optimal viewing.

Color Settings

Customizing screen color temperature and gamma values.

Display Settings

Adjusting image position, size, and clarity.

Other Settings

Configuring language and power indicator status.

MY KEY Setting Function

Customizing a button for quick access to favorite functions.

FUNC. Setting (Picture Mode)

Selecting predefined picture modes for text, photo, video, or games.

SUPER ENERGY SAVING Function

Enabling features to save energy and reduce CO2 emissions.

DUAL DISPLAY and DUAL WEB Features

Features for using multiple monitors or efficient web browsing.

Troubleshooting Monitor Issues

No Image or Signal Problems

Addresses issues with power, signal detection, and "OUT OF RANGE" messages.

OSD Lock Issues

Explains how to lock/unlock the OSD menu settings.

Display Image Adjustments

Solutions for incorrect display position, bars, or noise.

Incorrect Screen Color and Blinking

Troubleshooting abnormal screen colors or flickering.

Monitor Recognition Issues

Resolving problems with the monitor not being recognized by the PC.

Resolution and Flickering

Guidance on selecting correct resolution to prevent screen flickering.

Monitor Specifications

22EA53T Model Specifications

Detailed technical specifications for the 22EA53T model.

23EA53T Model Specifications

Detailed technical specifications for the 23EA53T model.

24EA53T Model Specifications

Detailed technical specifications for the 24EA53T model.

Preset Modes and Indicator Status

Information on supported display modes and indicator light meanings.

Proper Posture Guidelines

Ergonomic Usage Advice

Advice on setting up the monitor and user posture for optimal viewing.

Declaration of Conformity

Model and Serial Number Recording

Guidance on locating and recording model and serial numbers for service.

ENERGY STAR Compliance Information

Information regarding the product's compliance with ENERGY STAR energy guidelines.
