CUSTOMIZING SETTINGS

Display

Press MENU button on the bottom of the Monitor set

to display the Menu OSD.

Select the "Next Menu" button to enter the more

option settings.

Select Display by pressing the ► button.

Enter to Display by pressing the ▼ button.

Set the options by pressing the ◄ or ► or ▼

buttons.

Select EXIT to leave the OSD menu.

To return to the upper menu or set other menu items,

use the up arrow (

) button.

Each option is explained below.

Menu > Next Menu > Desplay Description

Horizontal To move image left and right.

Vertical To move image up and down.

Clock To minimize any vertical bars or stripes visible on the screen background.The

horizontal screen size will also change.

Phase To adjust the focus of the display. This item allows you to remove any horizontal

noise and clear or sharpen the image of characters.

Questions and Answers:

Need help?

Do you have a question about the LG 22EA53T-P and is the answer not in the manual?

LG 22EA53T-P Specifications

General

3D	No
Pixel pitch	0.2745 x 0.274 mm
Aspect ratio	16:9
Display surface	-
Display diagonal	21.5 \
Display technology	LED
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 83 kHz
Contrast ratio (dynamic)	5000000:1
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	720 x 400, 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
HDCP	Yes
HDMI ports quantity	0
Product color	Black
Tilt angle range	-5 - 20 °
Panel mounting interface	75 x 75 mm
AC input voltage	100 - 240 V
Power consumption (standby)	0.3 W
Power consumption (typical)	25 W
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Package depth	98 mm
Package width	567 mm
Package height	371 mm
