SPECIFICATION
1. Application Range
This spec sheet is applied all of the TV used LA31A chassis.
2. Specication
Each part is tested as below without special appointment
1) Temperature : 25 ˚C ± 5 ˚C (77 ˚F ± 9 ˚F),
CST : 40 ˚C ± 5 ˚C
2) Relative Humidity : 65 % ± 10 %
3) Power Voltage : Standard input voltage
(100 V - 240 V ~, 50 / 60 Hz)
· Standard Voltage of each products is marked by models
4) Specication and performance of each parts are followed
each drawing and specication by part number in accord-
ance with BOM.
5) The receiver must be operated for about 5 minutes prior to
the adjustment.
3.Test method
1) Performance : LGE TV test method followed
2) Demanded other specication
- Safety : CE,IEC specication
- EMC : CE,IEC specication
NOTE : Specications and others are subject to change without notice for improvement.
4. General specication
4.1. TV
No Item Specication Remarks
1 Market AMERICA, CANADA, MEXICO
2 Receiving system ATSC / NTSC-M / 64 & 256 QAM
3 Available Channel 1) VHF : 02~13
2) UHF : 14~69
3) DTV : 02-69
4) CATV : 01~135
5) CADTV : 01~135
4 Component Input (1EA) Y/Cb/Cr , Y/Pb/Pr
5. CVBS Input (1EA) NTSC 1 System(Rear) : NTSC
CVBS Video input is used by common port with Component.
6 RGB Input RGB-PC Analog (D-SUB 15Pin)
7 HDMI Input (2EA) HDMI1/2 Rear / HDMI version 1.4/ support PC
Support HDCP/HDMI2 : MHL Support
8 Audio Input (2EA) RGB/DVI Audio
Component & CVBS
L/R Input
CVBS Audio input is used by common port with Component.
9 Earphone out (1EA) Antenna, AV, Component, RGB,
HDMI1/2
10 Headphone out (1EA) Antenna, AV, Component, RGB,
HDMI1/2
Side 1EA
11 USB (1EA) EMF, DivX HD,
For SVC (download)
Side 1EA
JPEG, MP3, DivX HD
12 Local Key (Touch)
