LG 23MA73D-PUP - Page 8

- 8 -
LGE Internal Use Only
Copyright © LG Electronics. Inc. All right reserved.
Only for training and service purposes
No. Resolution H-freq(kHz) V-freq(Hz) Pixel clock(MHz) Remark
1 720* 480 31.469 / 31.5 59.94 / 60 27.00/ 27.03 SDTV 480P
2. 720*576 31.25 50.00 27.864 SDTV 576P
3. 1280*720 37.50 50.00 74.250 HDTV 720P
4 1280* 720 44.96 / 45 59.94 / 60 74.17/ 74.25 HDTV 720P
5 1920* 1080 33.72 / 33.75 59.94 / 60 74.17/ 74.25 HDTV 1080I
6 1920* 1080 28.125 50.00 74.25 HDTV 1080I
7 1920* 1080 27.00 24 74.25 HDTV 1080P
8 1920* 1080 33.75 30.00 74.25 HDTV 1080P
9 1920* 1080 56.250 50 148.5 HDTV 1080P
10 1920* 1080 67.43 / 67.5 59.94 / 60 148.35/ 148.50 HDTV 1080P
5.2. HDMI (DTV)
5.3. Component
No
Specication
Remark
Resolution H-freq(kHz) V-freq(Hz) Pixel clock( MHz)
1. 720* 480 15.73 59.94 13.500 SDTV, DVD 480I( 525I)
2. 720* 480 15.75 60.00 13.514 SDTV, DVD 480I( 525I)
3. 720* 576 15.625 50.00 13.500 SDTV, DVD 576I( 625I) 50Hz
4. 720* 480 31.47 59.94 27.000 SDTV 480P
5. 720* 480 31.50 60.00 27.027 SDTV 480P
6. 720* 576 31.25 50.00 27.000 SDTV 576P 50Hz
7. 1280* 720 44.96 59.94 74.176 HDTV 720P
8. 1280* 720 45.00 60.00 74.250 HDTV 720P
9. 1280* 720 37.50 50.00 74.25 HDTV 720P 50Hz
10. 1920* 1080 33.72 59.94 74.176 HDTV 1080I
11. 1920* 1080 33.75 60.00 74.250 HDTV 1080I
12. 1920* 1080 28.125 50.00 74.250 HDTV 1080I 50Hz
13. 1920* 1080 56.25 50 148.5 HDTV 1080P
14. 1920* 1080 67.432 59.94 148.350 HDTV 1080P
15. 1920* 1080 67.5 60.00 148.5 HDTV 1080P
