LG 24MP48HQ User Manual

18
ENG
ENGLISH
CUSTOMIZING SETTINGS
Button Description
Accesses the main menus.(See p.19)
OSD Locked/OSD
Unlocked
This function allow you to lock the current control settings, so that
they cannot be inadvertently changed.
Press and hold the MENU button for several seconds. Then OSD
of “OSD Lock” will appear. After that, user can select lock or unlock
by pressing left/right button.
If user selects the “Lock” icon by pressing the “OK” button, the
message “OSD Locked” will appear. Otherwise, “OSD Unlocked”
will appear. After selecting the “Lock”, If you want to change to
Unlock, you can push the “MENU” button for several seconds. The
message “OSD Unlocked” will appear.
Use this button to enter Reader Mode menu. Its function works to display screen as
paper-like picture for Eye comfort.If you want to more information(See p.25).
Use this button to enter SMART ENERGY SAVING , Picture Mode, Color Weakness
menus.(See p.26~28)
When adjusting your display settings, always press the AUTO button on the MONITOR
SETUP OSD. (Only supported in Analog Mode)
The best display
mode
20MP48A
1440 x 900 @ 60 Hz
22MP48A
22MP48D
22MP48HQ
23MP48D
23MP48HQ
24MP48HQ
27MP48HQ
1920 x 1080 @ 60 Hz
You can choose the input signal.
• When two input signals are connected, you can select the input signal (D-SUB/DVI-D/
HDMI) you want.
• When only one signal is connected, it is automatically detected. The default setting is
D-SUB.
EXIT
EXIT the OSD(On Screen Display).
(Power Button)
Turns the power on or off.
Power Indicator The power indicator stays white if the display is running properly (On
Mode). If the display is in Sleep Mode, the power indicator blinks
white.

LG 24MP48HQ Specifications

General

3D	No
Pixel pitch	0.2745 x 0.2745 mm
Aspect ratio	16:9
Screen shape	Flat
Display surface	-
Display diagonal	24 \
Display technology	LED
Contrast ratio (dynamic)	1000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Plug and Play	Yes
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Annual energy consumption	103 kWh
Power consumption (typical)	25 W
Sustainability certificates	EPEAT Gold, ENERGY STAR
Certification	TCO, UL(cUL), TUV-type, FCC-B, CE, EPA 6.0, ErP, EPEAT, Windows
Product color	Black
Package depth	- mm
Package width	609 mm
Package height	381 mm
Package weight	4127.69 g
Cables included	AC, HDMI, VGA

Weight and Dimensions

Depth (with stand)	187.4 mm
Height (with stand)	409 mm
Weight (with stand)	2800 g
Depth (without stand)	62.5 mm
Width (without stand)	549.9 mm
Height (without stand)	330.4 mm
Weight (without stand)	2600 g
