LG 24MP48HQ User Manual

22
ENG
ENGLISH
CUSTOMIZING SETTINGS
Color
1
Press
MENU
button on the bottom of the Monitor set
to display the
Menu
OSD.
2
Select the "
Next Menu
" button to enter the more
option settings.
3
Select
Color
by pressing the ► button.
4
Enter to
Color
by pressing the ▼ button.
5
Set the options by pressing the ◄ or ► or ▼
buttons.
6
Select
EXIT
to leave the OSD menu.
To return to the upper menu or set other menu items,
use the up arrow ( ) button.
Each option is explained below.
Menu > Next Menu > Color Description
Gamma Set your own gamma value. : Gamma 0, Gamma 1, Gamma 2, Off on
the monitor, high gamma values display blackish images and low gamma
values display whitish images.
If user don't want adjusted gamma, user can select Gamma off.
Color Temp Custom
• Red:
Set your own red color levels.
• Green:
Set your own green color levels.
• Blue:
Set your own blue color levels.
Select the screen color.
Warm:
Set the screen to warm color temperature (more red).
Medium:
Set the screen to medium color temperature.
Cool:
Set the screen to cool color temperature (more blue).
Six Color Sets and stores the hue and saturation for six colors(Red/Green/Blue/Cyan/
Magenta/Yellow) to satisfy the color requirements of a user.
Hue Adjusts the screen hue.
Saturation Adjusts the color sharpness on the screen. Lower values make
the color sharpness weaker and colors lighter while higher
values make the color sharpness stronger and colors dark.
Color Reset Resets the color settings to the factory default settings for the current input
device.

LG 24MP48HQ Specifications

General

3D	No
Pixel pitch	0.2745 x 0.2745 mm
Aspect ratio	16:9
Screen shape	Flat
Display surface	-
Display diagonal	24 \
Display technology	LED
Contrast ratio (dynamic)	1000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Plug and Play	Yes
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Annual energy consumption	103 kWh
Power consumption (typical)	25 W
Sustainability certificates	EPEAT Gold, ENERGY STAR
Certification	TCO, UL(cUL), TUV-type, FCC-B, CE, EPA 6.0, ErP, EPEAT, Windows
Product color	Black
Package depth	- mm
Package width	609 mm
Package height	381 mm
Package weight	4127.69 g
Cables included	AC, HDMI, VGA

Weight and Dimensions

Depth (with stand)	187.4 mm
Height (with stand)	409 mm
Weight (with stand)	2800 g
Depth (without stand)	62.5 mm
Width (without stand)	549.9 mm
Height (without stand)	330.4 mm
Weight (without stand)	2600 g
