LG 24MP48HQP - DPM Troubleshooting and Waveforms

- 22 -
Copyright © 2010 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
3. TROUBLE IN DPM
CHECKH/VSYNCLINE
TroubleinDPM
IC100 PIN41,42
CHECKPC.PCisgoingtotheDPM
mode
YES YES
NO
NO
TroubleinIC100
CheckR135&137
