If we select 1024x768@75Hz , our set
1
Supported Sync. Type
Separate Sync., Digital
2 Operating Frequency
Analog/
Digital
Horizontal 30  83kHz
20MP48A&24/27MP4
8HQ
Vertical 56  75 Hz
HDMI
Horizontal 30  83kHz
24/27MP48HQ
Vertical
56Hz ~ 75Hz
3 Resolution
Analog/
Digital
Max 1440*900@60Hz
20MP48A
Recommend 1440*900@60Hz
Analog/
Digital
Max. 1920×1080 @ 60Hz
24/27MP48HQ
Recommend 1920×1080 @ 60Hz
HDMI
Max. 1920×1080 @ 60Hz
24/27MP48HQ
Recommend 1920×1080 @ 60Hz
4 Input Voltage Voltage :100 – 240 Vac
5 Inrush Current Cold Start : 50 A Hot : 120 A
6
Operating Condition
Sync
(H/V)
Video LED Wattage
On Mode
On/On Active white
24MP48HQ:25W(Typ)
Test condition
1.1920x1080@60Hz
2. burst pattern
3. 100~240V
4. After aging 30min
20MP48A:17W(Typ)
27MP48HQ:28W(Typ)
On/On Active white
24MP48HQ:29W(Max)
20MP48A:21W(Max)
27MP48HQ:32W(Max)
Sleep Mode
(D-SUB , DVI, HDMI)
Off/On
On/Off
Off/Off
Off
white
Blinki
ng
≤ 0.3W
측정방법) 제어판 Æ
전원 옵션에서 디스
플레이 끄기와 PC를
절전모드로 하기 두
가지 설정이 있는데,
PC를 절전모드로 하
기만 선택하고 측정
해야 함.
Off Mode
(Power switch off)
- - Off ≤ 0.3 W(Typ.)
Smart Energy
Saving
Low/high
/off
On
white
24MP48HQ/27MP48HQ
Low:10%~20%,2W/H
High:20%~30%,4W/H
20MP48A
Low:10%~20%,1W/H
High:20%~30%,3W/H
-Test Condition
(1)
EPA6.0
24MP48HQ<22W/H
20MP48A<15W/H
27MP48HQ<25W/H
margin >7%
Worst :margin>0
Adjust the center l
uminance to 200 c
d/㎡
4. Engineering Specification

LG 24MP48HQP Specifications

General

Brand	LG
Model	24MP48HQP
Category	Monitor
Language	English
