LG 27MP77HM User Manual

9
ENG
ENGLISH
ASSEMBLING AND PREPARING
Setting up the Monitor set
Attaching the Stand Base
Stand Body
Stand Hinge
Stand Body
Stand Base
y
To protect the screen from scratches, cover
the surface with a soft cloth.
CAUTION
2
Check the direction of the stand body
(front, back) and then mount the stand body
onto the stand hinge.
Tighten two screws into the back of the stand
body .
1
Place the screen face down.
Screws
3
Insert the
stand base
into the hook of the
stand body
.
Tighten the screw to the right.
1
2
4
Attach the Cable holder.
Applying excessive force when tightening
the screws may cause damage to the moni-
tor. Damage caused in this way will not be
covered by the product warranty.
CAUTION
It may hurt your foot off the stand, so be
careful.
CAUTION
Cable holder
1
2
Insert the
cable holder
into the hook of the
stand body
.
Press down the
cable holder
as shown in
illustration.
2
1
