LG 29MN33D - TROUBLE SHOOTING; No Power

- 13 -
LGE Internal Use Only
Copyright © LG Electronics. Inc. All right reserved.
Only for training and service purposes
TROUBLE SHOOTING
1. No Power
Check C820 All
Voltage Level (19V)
Check Power connector
OK ?
Replace Adapter
N N
Check IC802 output
Voltage Level (5V)
Replace IC802 &
Recheck
N
Check IC2602 Output
Voltage Level (3.3V_ST)
Replace IC2602
N
Y
Check IC800 Output
Voltage Level (5V)
Replace IC800
N
Y
Y
Y
Y
Check IC804 Output
Voltage Level (12V)
Replace IC804
N
Y
Check IC810 Output
Voltage Level (2.5V)
Replace IC810
N
Check X201 Clock
24MHz
Replace X201
N
Check X201 Clock
24MHz
Replace X201
N
Replace IC100 Flash Memory
Y
Check IC806 Output
Voltage Level (1.15V)
Replace IC806
N
Y
Y
Check IC807 Output
Voltage Level (1.5V)
Replace IC807
N
